ZHK INOVA

Perfectly adapted

T2/TB2 as standard

The ZHK INOVA unit series is characterised by enormous flexibility. The basis for this is the ZHK INOVA casing, which meets the Eurovent-certified standard T2/TB2. We are able to adapt our Air Handling Units to your needs.

We provide freely configurable unit systems and can rely on a wide range of high-quality components. The unit sizes and shapes can be perfectly adapted to the general conditions on site.

Download:

ZHK INOVA (en)
  • 50 mm double-walled casing
  • Sheet thicknesses : up to 1.5 mm sheet metal
  • Non-flammable mineral wool with a density up to 150 kg/m³
  • Casing data (MB ZHK INOVA) according to
    EN 1886 certified:

    • Mechanical casing strength: Class D1(M)
    • Casing leakage at –400 Pa: Class L1(M)
    • Casing leakage at +700 Pa: Class L1(M)
    • Filter bypass leakage: Class F9 (M)
    • Heat transmission: Class T2
    • Thermal bridging factor: Class TB2

Download:

ZHK INOVA (en)

Customer-specific solutions
freely configurable unit system

as Standard
for ZHK INOVA units
